Specification:
1. Magnification: Continuous zoom 7X to 50X
2. Head: 45-degree inclined 360-degree swiveling trinocular
3. Eyepiece: WF10X/22MM
4. Objective: 0.7-5.0X
5. Camera connector: 0.5X
6. Camera: 4K camera
7. Monitor and eyepiece: Synchronous zoom
8. Stand: 410 x 300mm
9. Accessories: 144 adjustable led light & dust proof Lens
10. Monitor: 15.6-inch 4K ultra HD monitor
Support Parameters:
1. Column aperture: 32mm
2. Lens aperture: 76mm
3. Center distance: 155mm
4. Lifting range: 50mm
Base Parameters:
1. Base size: 410 x 300mm
2. Pillar: 240mm x 32mm
3. Silicone pad size: 330 x 198mm
Wide-angle Eyepieces 10X/22:
1. Magnification: 10X
2. Wide field of view 22mm
3. Matching size : 30mm
4. Applicable models: Stereoscopic, fixed and continuous magnification microscopes
0.5X CTV Len:
1. The material is all metal, the black part is aluminum alloy, and the silver part is copper chrome-plated bayonet
2. The adapter ring can use LCD to focus, this kind of focus method is manual focus
3. The adapter has a transparent mirror inside, which can help the microscope display and the other display to achieve synchronous zooming
Monitor:
1. 15.6-inch 4K ultra HD monitor
2. Resolution ratio: 3840 x 2160 30Hz
3. Support for input resolution: 3840 x 2160 30Hz; 1920 x 1080 60Hz
4. Proportion of the screen: 16:9
144 LED Ring Light:
1. Input: AC 100~240V 50/60Hz
2. Output: DC 12V, Max 700mA
3. Number of lights: 144 LEDs
4. Inside diameter: 60mm
Package includes:
1. Microscope x 1
2. Aluminum Alloy Plate
3. 144 LED Light x 1
4. Silicone Pad x 1
5. Dustproof lens x 1
6. 0.5X CTV Lens x 1
7. Display x 1
8. 4K CCD Camera x 1
