Features:
1. 7.0X-50X trinocular microscope
2. 10-inch Monitor with 16MP HDMI camera
3. Multifunctional aluminum alloy repair base
4. Magnification: Big continuous zoom 7.0X to 50X
5. Head: 45-degree inclined 360-degree swiveling trinocular
6. Eyepiece: WF10X/22MM Adjust the focal
7. Barlow Lens: 0.5X & 0.7&2.0X(Optional)
8. Objective: 0.70~5.0X
9. Camera connector: 1/2CTV
10. Monitor and eyepiece. Synchronous zoom
11. Camera: Different models optional
12. Boom Stand: 250mm x 32mm pillar, 410 x 300mm Plate
13. Accessories: 144 adjustable LED light & dustproof Lens
Base Parameters:
1. Base size: 410 x 300mm
2. Pillar: 240mm x 32mm
3. Silicone pad size: 330 x 198mm
Monitor:
1. Model Number: YS101W
2. Resolution: 1080P
3. Monitor size: 10-inch
4. Aspect ratio: 16:10
5. IPS display resolution: 1280 x 800
6. Output port: HDMI
7. Panel brightness: 400cd/m2
8. Contrast: 1300:1 (Min.)(transmission)
9. Viewing angle: IPS full view
10. Display area: 215 x 121mm
11. WiFi distance: Ten meters
12. Display mode: IPS, always black display, transmissive
Wide-angle Eyepieces 10X/22:
1. Magnification: 10X
2. Wide field of view 22mm
3. Matching size: 30mm
4. Applicable models: Stereoscopic, fixed, and continuous magnification microscopes
0.5X CTV Len:
1. The material is all metal, the black part is aluminum alloy, and the silver part is a copper chrome-plated bayonet
2. The adapter ring can use LCD to focus, this kind of focus method is manual focus
3. The adapter has a transparent mirror inside, which can help the microscope display and the other display achieve synchronous zooming
144 LED Ring Light:
1. Input: AC 100~240V 50/60Hz
2. Output: DC 12V, Max 700mA
3. Light color: White
4. Number of lights: 144 LEDs
5. Inside diameter: 60mm
Package includes:
1. Microscope x 1
2. Aluminum Alloy Plate
3. 144 LED Light x 1
4. Silicone pad x 1
5. Dustproof lens x 1
6. 0.5X CTV Lens x 1
7. HD Monitorx 1
